MODEL |
LKAD033D-D |
|
|
OUTPUT |
CURRENT |
72 0mA |
|
DC VOLTAGE |
DC26 ~42V |
|
|
RATED POWER |
Max 30 W |
|
|
RIPPLE CURRENT |
±5% |
|
|
NO LOAD VOLTAGE |
42VDC (max) |
|
|
RIPPLE & NOISE |
1000mV p -p |
|
|
OUTPUT SYMBOL |
LED +: The positive pole for 3000K & 6000K CCT circuit LED -: The negative pole for 3000K & 6000K CCT circuit |
|
|
INPUT |
VOLTAGE RANGE |
100~2 40VAC |
|
FREQUENCY RANGE |
50/60Hz |
|
|
EFFICIENCY |
85% @ Full Load, Input 220VAC |
|
|
AC CURRENT |
0.136A @ Full Load, Input22 0VAC |
|
|
POWER FACTOR |
>0.90 @ Full Load, Input 220VAC |
|
|
THD |
<10% @ Full Load, Input 220VAC |
|
|
LEAKAGE CURRENT |
<2.5mA/220VAC |
|
|
PROTEC TION |
SHORT CIRCUIT |
Auto Restart |
|
OVER VOLTAGE |
≤120%,Protection type:Shutdown o/p voltage, re-power on to recover |
|
|
OVER TEMPERATURE |
Shut down o/p voltage, re -power on to recover |
|
|
ENVIRO MENT |
WORKING TEMP. |
-20℃～+55 ℃ |
|
WORKING HUMIDITY |
To 85% Relative Humidity(Non - condensing) |
|
|
|
STORAGE TEMP. |
-30℃～+75 ℃ |
|
STORAGE HUMIDITY |
To 95% Relative Humidity(Non - condensing) |
|
|
INGRESS PROTECTION |
IP20 |
|
|
VIBRATION |
10 -500HZ 2G10min/cycle period for 60 minutes each axes |
|
|
|
CONDUCTED EMISSIONS |
EN55015 Class B |
|
CONFO |
RADIATED EMISSIONS |
EN55015 Class B |
|
RMITY & STANDA |
GENERAL AND SAFETY REQUIREMENTS |
EN61347 - 1 |
|
RDS |
DALI STANDARDS |
Comply with IEC62386 -101,102,207 |
|
OTHER |
DIMENSIONS |
155 (L) × 45(W) × 27(H)mm |
