LKAD057D-C 54W 5-42V 1200mA 0-10V Dimming LED drivers
  • LKAD057D-C 54W 5-42V 1200mA 0-10V Dimming LED drivers

LKAD057D-C 54W 5-42V 1200mA 0-10V Dimming LED drivers

  • Product model : LKAD057D-C
  • Input voltage : 200-240Vac
  • Output power(W) : 54W
  • Output voltage : 5-42Vdc
  • Output current(A) : 600mA/1200mA
  • Light adjustment : 0-10V Dimming
  • Size(MM) : Dia 75mm x H 22mm
Authentication:
Skype
  • Product Detail
  • Send Inquiry
  • Download

LKAD057D-C 54W 5-42V 1200mA 0-10V Dimming LED drivers

Features

  • 200-240VAC(50/60Hz) Input
  • High efficiency, high power factor, high stability, high light ratio
  • Flicker free
  • Short circuit,over voltage,over current and over temperature protection;
  • Remote control performance is stable, any angle direction can be controlled.
  • independent, ClassⅡ constant current type;
  • degree of protection IP20;
  • can be achieved Lighting,ceiling light,down light and panel light;
  • 3 years warranty.

More Details

Model

LKAD057D-C

輸入Input

輸入電壓范圍/Input Voltage range

100-277V

頻率/Frequency

50/60hz

諧波/THD

≤10%/240VAC

功率因數/Power factor

0.96/240VAC

輸入電流 Input current（mA)

250MA

待機功耗 stand_by power

≦0.8W

浪涌電流 Inrush

Current(Max.)

≤30A@230VAC

漏電流 Leakage Current

<1MA/240V

輸出Output

額定電壓/Rated voltage

40V

空載電壓/No-load Voltage

45V

工作電壓范圍/working voltage range

20-40V

可選擇電流規格/selectable current specs

1500MA±15MA

電流精度/Current precision

(+/-)3%

額定功率/Rated power

59W

開機延時/Setup Time

≤0.5s/230VAC

輸出線性調整率Output Line Regulation

±5%

溫度漂移temperature drift

±10%
